Q-600

Collect
Product parameters
ParametersSpecification
ModelQ600
Dispensing Range X/Y/ZSingleValve:450*450*60
Dual Valve Simultaneous: 350*450*40mm
Rotation&Tilting:300*450*40mm
Transport Height900+30mm
Conveyor Edge Distance4+1mm
PCB Max/Min SizeXY50*50-450*450mm
Product weight≦3KG
Maximum Speed1000mm/s(XY)
Acceleration1.0g
Motion Driven ModeServo Motor+Ball Screw
Dual Valve Simultaneous ( operation)Spcaing 50-100mm
Rotation & Tilting Function ( operation)Rotation 0°/90°
Tilting 土 30°
Rotation 土 90°
Tilting 土25°
Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Dispenser

  • Dispensing Range: 300*450*40mm-450*450*60mm

  • Maxim Speed: 1000mm/s

  • Acceleration: 1.0G

  • Position Accuracy: ±30um@3sigma(X,Y), ±20um@3sigma(Z)

  • Repeat Position Accuracy: ±15um@3sigma(X,Y) ,±5um@3sigma(Z)

  • Substrate Size: 50*50mm-450*450mm

  • Controllable Dispensing Commands:Point, Line. Multi- section line, Arc, Circle,

    Rectangle Filling, Circular Filling and 3D Dynamic Trajectory;

  • Multi-dispensing Process: Encapsulation, Under Fill, Dam and Fill, SMA and Conductive

    Silver Epoxy, etc.

  • Multi Valves Available Can Be Choosed by Customer

  • It's Customizable According the Technical Requirement from End-customer
