Product Detail

DG

Collect
Product parameters
ParametersSpecification
ModelDG
Screen Frame Size470mm x 370mm~737mm x 737mm
Substrate Handling Size (minimum)50mm (X) x 50mm (Y)
Substrate Handling Size (maximum)400mm (X) x340mm (Y)    Options:460mm(X)x340mm(Y)
                                                        510mm(X)x340mm(Y)
Cycle Time7s
Screen Frame Thickness20mm -40mm
Substrate Thickness0.4mm -6mm
Print Pressure0kg -20kg
Print Speed1 -200mm/s
Print Gap0mm -20mm
Substrate SeparationSpeed:0.1-20mm/sec
Distance:0mm - 20mm
Apply paste optionSolder paste，Printing ink, Silver paste


Product Description
Solder Paste Printing Machine DG

  • Classic Z-axis lifting platform

  • Integrated molding structure of the entire machine frame

  • Scraper upper and lower direct connection screw drive

  • Automatic intelligent cleaning system for steel mesh

  • Adjustable size of stencil frame

  • Printing cycle time 7s
