Product Detail

DGHP

Collect
Product parameters
ParametersSpecification
ModelDGHP
Screen Frame Size470mm x 370mm~737mm x 737mm
Substrate Handling Size (minimum)50mm (X) x 50mm (Y)
Substrate Handling Size (maximum)510mm (X) x510mm (Y)                Options: 610mm(X)x510mm(Y)

Cycle Time7s
Screen Frame Thickness20mm -40mm
Substrate Thickness0.4mm -6mm
Print Pressure0kg -20kg
Print Speed1 -200mm/s
Print Gap0mm -20mm
Substrate SeparationSpeed:0.1-20mm/sec
Distance:0mm - 20mm
Apply paste optionSolder paste，Printing ink, Silver paste
Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Solder Paste Printer

  • Automatic stencil positioning system

  • Automatic platform calibration system

  • Vaccum adsorption of substrate

  • Vaccum adsorption of stencil

  • Adjustable size of stencil frame

  • Maxim Printing size 510*510mm(option to 610*510mm)
