Our SMT machines

Home >> Our SMT machines >>Solder Paste Printing Machine >> DGL-S
Product Detail

DGL-S

Collect
Product parameters
ParametersSpecification
ModelDGL-S
Screen Frame Size 737mm x 300mm ~ 2300mm x737mm
Substrate Handling Size (minimum)80mm (X) x 50mm (Y)
Substrate Handling Size (maximum)2000mm (X) x510mm (Y)
Cycle Time12s
Screen Frame Thickness20mm - 40mm
Substrate Thickness0.4mm - 6mm
Print Pressure0kg - 20kg
Print Speed6mm/s-120mm/s
Print Gap0mm - 20mm
Substrate Separation Speed:0.1- 20mm/sec
 Distance:0mm - 30mm
 Apply paste optionSolder paste，Printing ink, Silver paste
 Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Solder Paste Printer

  • Automatic platform calibration system

  • Integrated molding structure of the entire machine frame

  • Flexible side clamping system

  • Automatic multi-cleaning system for steel mesh

  • Classic second platform calibration

  • Capable for 5G,New Energy,Power Battery and New Display

  • Printing size:80*50mm-2000*510mm
