Product Detail

DGL-E

Collect
Product parameters
ParametersSpecification
ModelDGL-E
Screen Frame Size 737mm x 737mm ~ 1200mm x900
Substrate Handling Size (minimum)100mm (X) x 80mm (Y)
Substrate Handling Size (maximum)850mm (X) x610mm (Y)
Cycle Time15s
Screen Frame Thickness20mm - 40mm
Substrate Thickness0.6mm - 6mm
Print Pressure0kg - 20kg
Print Speed6mm/s-120mm/s
Print Gap0mm - 20mm
Substrate Separation Speed:0.1- 20mm/sec
 Distance:0mm - 30mm
 Apply paste optionSolder paste，Printing ink, Silver paste
 Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Solder Paste Printer

  • Automatic stencil positioning

  • Automatic platform calibration

  • Maxim printing size:850*610mm

  • PCB 2D  inspection

  • Flexiable side clamping

  • Vacuum adsorption of substrate
