Product Detail

DGH

Collect
Product parameters
ParametersSpecification
ModelDGH
Screen Frame Size470mm x 370mm~737mm x 737mm
Substrate Handling Size (minimum)50mm (X) x 50mm (Y)
Substrate Handling Size (maximum)400mm (X) x340mm (Y)           Options:460mm(X)x340mm(Y)
                                                               510mm(X)x340mm(Y)
Cycle Time7s
Screen Frame Thickness20mm - 40mm
Substrate Thickness0.4mm - 6mm
Print Pressure0kg - 20kg
Print Speed1 - 200mm/s
Print Gap0mm - 20mm
Substrate SeparationSpeed:0.1- 20mm/sec
Distance:0mm - 20mm
Apply paste optionSolder paste，Printing ink, Silver paste
Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Solder Paste Printer

  • Classic small platform for calibration system

  • Max printing size: 400*340mm

  • Automatic stencil positioning system

  • Automatic multi-cleaning system for steel mesh

  • Automatic top clamping

  • Printing cycle time 7s
