DGF

Collect
Product parameters
ParametersSpecification
ModelDGF
Screen Frame Size 470mm x 370mm~737mm x 737mm
Substrate Handling Size (minimum)50mm (X) x 50mm (Y)
Substrate Handling Size (maximum)510mm (X) x510mm (Y)
Cycle Time7s
Screen Frame Thickness20mm - 40mm
Substrate Thickness0.4mm - 6mm
Print Pressure0kg - 20kg
Print Speed1 - 200mm/s
Print Gap0mm - 20mm
Substrate Separation Speed:0.1- 20mm/sec
 Distance:0mm - 20mm
 Apply paste optionSolder paste，Printing ink, Silver paste
 Voltage220Volts +/- 10%.Single phase 50/60Hz


Product Description
Automatic Solder Paste Printer

  • Classic Z-axis lifting platform

  • Integrated molding structure of the entire machine frame

  • Scraper upper and lower direct connection screw drive

  • Automatic intelligent cleaning system for steel mesh

  • Adjustable size of stencil frame

  • Printing cycle time 7s

  • Automatic stencil positioning

  • Automatic platform calibration
